5G Frequency bands and channel bandwidths

the NR bands are defined with a prefix of "n". When the NR band is overlapping with the 4G LTE band, they share the same band number.

• Frequency Range 1
•


• Frequency Range 2

Frequency range designation	Corresponding frequency range
FR1	410 MHz – 7125 MHz
FR2	24250 MHz – 52600 MHz

Frequency Range 1

NR operating band	Uplink (UL) operating band BS receive / UE transmit FUL_low   –  FUL_high	Downlink (DL) operating band BS transmit / UE receive FDL_low   –  FDL_high	Duplex Mode
n1	1920 MHz – 1980 MHz	2110 MHz – 2170 MHz	FDD
n2	1850 MHz – 1910 MHz	1930 MHz – 1990 MHz	FDD
n3	1710 MHz – 1785 MHz	1805 MHz – 1880 MHz	FDD
n5	824 MHz – 849 MHz	869 MHz – 894 MHz	FDD
n7	2500 MHz – 2570 MHz	2620 MHz – 2690 MHz	FDD
n8	880 MHz – 915 MHz	925 MHz – 960 MHz	FDD
n12	699 MHz – 716 MHz	729 MHz – 746 MHz	FDD
n14	788 MHz – 798 MHz	758 MHz – 768 MHz	FDD
n18	815 MHz – 830 MHz	860 MHz – 875 MHz	FDD
n20	832 MHz – 862 MHz	791 MHz – 821 MHz	FDD
n25	1850 MHz – 1915 MHz	1930 MHz – 1995 MHz	FDD
n26	814 MHz – 849 MHz	859 MHz – 894 MHz	FDD
n28	703 MHz – 748 MHz	758 MHz – 803 MHz	FDD
n29	N/A	717 MHz – 728 MHz	SDL
n303	2305 Mhz – 2315 MHz	2350 MHz – 2360 MHz	FDD
n34	2010 MHz – 2025 MHz	2010 MHz – 2025 MHz	TDD
n38	2570 MHz – 2620 MHz	2570 MHz – 2620 MHz	TDD
n39	1880 MHz – 1920 MHz	1880 MHz – 1920 MHz	TDD
n40	2300 MHz – 2400 MHz	2300 MHz – 2400 MHz	TDD
n41	2496 MHz – 2690 MHz	2496 MHz – 2690 MHz	TDD
n48	3550 MHz – 3700 MHz	3550 MHz – 3700 MHz	TDD
n50	1432 MHz – 1517 MHz	1432 MHz – 1517 MHz	TDD1
n51	1427 MHz – 1432 MHz	1427 MHz – 1432 MHz	TDD
n53	2483.5 MHz – 2495 MHz	2483.5 MHz – 2495 MHz	TDD
n65	1920 MHz – 2010 MHz	2110 MHz – 2200 MHz	FDD4
n66	1710 MHz – 1780 MHz	2110 MHz – 2200 MHz	FDD
n70	1695 MHz – 1710 MHz	1995 MHz – 2020 MHz	FDD
n71	663 MHz – 698 MHz	617 MHz – 652 MHz	FDD
n74	1427 MHz – 1470 MHz	1475 MHz – 1518 MHz	FDD
n75	N/A	1432 MHz – 1517 MHz	SDL
n76	N/A	1427 MHz – 1432 MHz	SDL
n77	3300 MHz – 4200 MHz	3300 MHz – 4200 MHz	TDD
n78	3300 MHz – 3800 MHz	3300 MHz – 3800 MHz	TDD
n79	4400 MHz – 5000 MHz	4400 MHz – 5000 MHz	TDD
n80	1710 MHz – 1785 MHz	N/A	SUL
n81	880 MHz – 915 MHz	N/A	SUL
n82	832 MHz – 862 MHz	N/A	SUL
n83	703 MHz – 748 MHz	N/A	SUL
n84	1920 MHz – 1980 MHz	N/A	SUL
n86	1710 MHz – 1780 MHz	N/A	SUL
n89	824 MHz – 849 MHz	N/A	SUL
n90	2496 MHz – 2690 MHz	2496 MHz – 2690 MHz	TDD5
n91	832 MHz – 862 MHz	1427 MHz – 1432 MHz	FDD9
n92	832 MHz – 862 MHz	1432 MHz – 1517 MHz	FDD9
n93	880 MHz – 915 MHz	1427 MHz – 1432 MHz	FDD9
n94	880 MHz – 915 MHz	1432 MHz – 1517 MHz	FDD9
n958	2010 MHz – 2025 MHz	N/A	SUL

NOTE 1:    UE that complies with the NR Band n50 minimum requirements in this specification         shall also comply with the NR Band n51 minimum requirements. NOTE 2:    UE that complies with the NR Band n75 minimum requirements in this specification         shall also comply with the NR Band n76 minimum requirements. NOTE 3:    Uplink transmission is not allowed at this band for UE with external vehicle-mounted antennas. NOTE 4:    A UE that complies with the NR Band n65 minimum requirements in this specification shall also comply with the NR Band n1 minimum requirements. NOTE 5:    Unless otherwise stated, the applicability of requirements for Band n90 is in accordance with that for Band n41; a UE supporting Band n90 shall meet the requirements for Band n41. A UE supporting Band n90 shall also support band n41. NOTE 6:    A UE that supports NR Band n66 shall receive in the entire DL operating band. NOTE 7:    A UE that supports NR Band n66 and CA operation in any CA band shall also comply with the minimum requirements specified for the DL CA configurations CA_n66B and CA_n66(2A) in the current version of the specification. NOTE 8:    This band is applicable in China only. NOTE 9:    Variable duplex operation does not enable dynamic variable duplex configuration by the network, and is used such that DL and UL frequency ranges are supported independently in any valid frequency range for the band.

•


https://pxhere.com/

Frequency Range 2

Band	ƒ (GHz)	Common name	Subset of band	Uplink / Downlink[B 1] (GHz)	Channel bandwidths[5] (MHz)
n257	28	LMDS		26.50 – 29.50	50, 100, 200, 400
n258	26	K-band		24.25 – 27.50	50, 100, 200, 400
n260	39	Ka-band		37.00 – 40.00	50, 100, 200, 400
n261	28	Ka-band	n257	27.50 – 28.35	50, 100, 200, 400

Reference

1 https://en.wikipedia.org/wiki/5G_NR_frequency_bands#Frequency_Range_2

2 3GPP TS38.101-1V16.3.0(2020-03)
